LGMG MT86D Mine Truck – Covering assy – L3602-2736010334
Category: Mine Truck > MT86D > M086DWA10
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | 86 China Ⅲ RH platform（LH cab） | 4190003509 | 1 |
| 2 | Bolt GB5782-M14*80EpZn-8.8 | 4011000832 | 10 |
| 3 | Washer GB96.1-14EpZn-300HV | 4015000188 | 20 |
| 4 | Support bracket | 27130103923 | 1 |
| 5 | Left fender assy | 27360111442 | 1 |
| 6 | Middle rack | 27360105422 | 1 |
| 7 | Right fender assy | 27360111432 | 1 |
| 8 | Support | 27360109212 | 1 |
| 9 | Bolt GB5783-M14*50EpZn-8.8 | 4011000338 | 4 |
| 10 | Washer GB97.1-14EpZn-300HV | 4015000177 | 11 |
| 11 | Bumper assembly | 27130114151 | 1 |
| 12 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 8 |
| 13 | Bolt GB5783-M12*50EpZn-8.8 | 4011000092 | 1 |
| 14 | Bolt GB5783-M12*45EpZn-8.8 | 4011000207 | 7 |
| 15 | Fog light protecting cap | 27130102161 | 2 |
| 16 | Washer GB97.1-5EpZn-300HV | 4015000110 | 8 |
| 17 | No longer used | 4013000118 | 8 |
| 18 | Bolt GB16674.1-M5*25EpZn-8.8 | 4011000586 | 8 |
| 19 | Adjustment shim 1 | 27130113171 | 3 |
| 20 | Adjustment shim 2 | 27130113181 | 3 |
| 21 | Trimmed gasket | 27130107671 | 4 |
| 22 | Front support base | 27130102494 | 1 |
| 23 | Trimmed gasket | 27130107681 | 4 |
| 24 | Trim washer | 27130104411 | 2 |
| 25 | Bolt GB5785-M16*1.5*50EpZn-8.8 | 4011000512 | 2 |
| 26 | Rubber | 27360112601 | 2 |
| 27 | Mudflap supporting plate | 27360112581 | 2 |
| 28 | Washer GB96.1-8EpZn-300HV | 4015000256 | 24 |
| 29 | Bolt GB5782-M8*30EpZn-8.8 | 4011010172 | 12 |
| 30 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 1 |
| 31 | Bolt GB5783-M16*60EpZn-8.8 | 4011000594 | 8 |
| 32 | Washer GB1230-16EpZn-45 | 4015000001 | 8 |
| 33 | Nut GB6170-M16EpZn-8 | 4013000016 | 8 |
| 34 | No longer used | 4015000305 | 8 |
| 35 | Washer GB97.1-16EpZn-300HV | 4015000181 | 2 |
| 36 | Nut GB6185.1-M14EpZn-8 | 4013010121 | 25 |
| 37 | Bolt GB5783-M14*55EpZn-8.8 | 4011010254 | 11 |
