LGMG Off-Highway Dump Truck 2023 – Cab thermal management mounting assembly – A0301-2703015474.S1A
Category: 2023 > Off-Highway Dump Truck > RTH136(EQ) > R1260Y3A0A504
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pipe | 27030147241 | 1 |
| 2 | pipe | 2703014725-002 | 1 |
| 3 | pipe | 2703014726-003 | 1 |
| 4 | pipe | 2703014727-003 | 1 |
| 5 | PIPE PSKT105C1 | 4190708992-002 | 1 |
| 6 | PIPE PSKT105C2 | 4190708993-002 | 1 |
| 7 | Plate | 27010113352 | 28 |
| 8 | Double hole R-type clamp R-D40*2-M10 | 4190707989 | 41 |
| 9 | Bolt GB5783-M10*20EpZn-8.8 | 4011000081 | 68 |
| 10 | Washer GB97.1-10EpZn-300HV | 4015000162 | 86 |
| 11 | Pipe | 27030122101 | 3 |
| 12 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 68 |
| 13 | Support | 27030147211 | 1 |
| 14 | Tee flow valve assy STF-01 | 4110706402 | 1 |
| 15 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 2 |
| 16 | Washer GB97.1-6EpZn-300HV | 4015000207 | 2 |
| 17 | Nut GB6185.1-M6EpZn-8 | 4013010117 | 2 |
| 18 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 19 |
| 19 | Plate | 27030147321 | 15 |
| 20 | Pipe clamp R-D40-M10 | 4190707973 | 17 |
| 21 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 8 |
| 22 | pipe | 2703014743-003 | 1 |
| 23 | Bolt GB5783-M10*70EpZn-8.8 | 4011000413 | 2 |
| 24 | Pipe | 27030147281 | 1 |
| 25 | pipe | 2703014739-002 | 1 |
| 26 | Clamp φ20-φ40 | 4190708281 | 22 |
| 27 | pipe1 | 2703014280-005 | 1 |
| 28 | pipe1 | 2703014280-006 | 1 |
| 29 | Pipe | 27030147221 | 1 |
| 30 | Pipe | 27030147231 | 1 |
