LGMG Off-Highway Dump Truck 2023 – Air filter muffler assy – J1001-2710012576.S1A
Category: 2023 > Off-Highway Dump Truck > CMTE106H > C106HE0A0A403
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Air filter silencer QXAC3P/4G319-500 | 4120711498 | 1 |
| 2 | Bracket 180*80*80 | 27100124101 | 1 |
| 3 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 4 |
| 4 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
| 5 | Nut GB6170-M8EpZn-8 | 4013000033 | 4 |
| 6 | Bolt GB5782-M10*50EpZn-8.8 | 4011000048 | 2 |
| 7 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 8 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
