LGMG AT40 2025 – Bracket assy 09 – M1500-2715014614.S1A
Category: 2025 > AT40 > A0400W3M0A201
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5782-M8*65EpZn-8.8 | 4011000301 | 1 |
| 2 | Bolt GB5782-M8*70EpZn-8.8 | 4011000591 | 1 |
| 3 | Washer GB97.1-8EpZn-300HV | 4015000072 | 3 |
| 4 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 5 | Cable tie HS-J117 | 4130704969 | 1 |
| 6 | Plate 102*30*3 | 27150143671 | 1 |
| 7 | Clamp 28*22 | 27150143651 | 1 |
| 8 | Bracket 115*30*36 | 27150143661 | 1 |
| 9 | Bolt GB5783-M10*25EpZn-10.9 | 4011000993 | 1 |
| 10 | Washer GB97.1-10EpZn-300HV | 4015000162 | 1 |
