LGMG Off-Highway Dump Truck 2023 – Engine assy – A1011-2701012106
Category: 2023 > Off-Highway Dump Truck > MT86H > M086HW3A0A019
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB96.1-12EpZn-300HV | 4015000186 | 2 |
| 2 | Bolt GB5783-M14*55EpZn-10.9 | 4011010277 | 1 |
| 3 | Bolt GB5782-M14*50EpZn-10.9 | 4011000988 | 4 |
| 4 | Engine front left leg | 27010109592 | 1 |
| 5 | Bolt GB5782-M16*60EpZn-8.8 | 4011000068 | 8 |
| 6 | Nut GB6185.1-M16EpZn-8 | 4013010122 | 8 |
| 7 | Plate | 27010109751 | 1 |
| 8 | Shock absorber 530903-45 | 4110001123 | 2 |
| 9 | Nut GB6185.1-M22EpZn-10 | 4013010139 | 4 |
| 10 | Washer GB97.1-22EpZn-300HV | 4015000184 | 4 |
| 11 | FR suspension cushion | 4110000331 | 2 |
| 12 | Bolt GB5782-M22*130EpZn-10.9 | 4011010256 | 4 |
| 13 | Frame | 27010109391 | 2 |
| 14 | Plate | 27010105441 | 2 |
| 15 | BEAM | 27010117182 | 1 |
| 16 | CARGO TANK ASSEMBLY | 27010117222 | 1 |
| 17 | Bolt GB5786-M14*1.5*40EpZn-10.9 | 4011000214 | 16 |
| 18 | Washer GB1230-14EpZn-45 | 4015000358 | 16 |
| 19 | Bolt GB5783-M16*60EpZn-10.9 | 4011010205 | 10 |
| 20 | Washer GB97.1-16EpZn-300HV | 4015000181 | 10 |
| 21 | Plate | 27010109781 | 1 |
| 22 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 4 |
| 23 | Plate | 27010113352 | 2 |
| 24 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 2 |
| 25 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
| 26 | Clamp | 26370001911 | 1 |
| 27 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 28 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 4 |
| 29 | Engine assy WP12G460E310 | 4110705523 | 1 |
| 30 | Engine front right leg | 27010109622 | 1 |
| 31 | Bolt GB5783-M14*65EpZn-10.9 | 4011010013 | 3 |
| 32 | Nut GB6185.1-M14EpZn-10 | 4013010135 | 8 |
| 33 | Trimmed gasket | 27010106821 | 2 |
| 34 | Bolt GB5786-M12*1.5*30EpZn-10.9 | 4011010276 | 2 |
