LGMG AT40 2025 – Chassis middle electrical module – K2001-2720017369.S1B
Category: 2025 > AT40 > A0400W3M0A105
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Start switch ZB2BA3C | 4130703874 | 1 |
| 2 | On-board lighting yqdq-np-4led | 4130712978 | 1 |
| 3 | Screw GB818-M4*20EpZn-4.8 | 4014000022 | 2 |
| 4 | Nut GB6170-M4EpZn-8 | 4013000025 | 2 |
| 5 | Lighting bracket 84*54*40 | 27200174101 | 1 |
| 6 | Bolt GB5783-M10*20EpZn-8.8 | 4011000081 | 4 |
| 7 | LED FR work lamp SG-GZ050C | 4130704856 | 2 |
| 8 | Emergency stop switch fixing bracket 108*85*60 | 27200174111 | 1 |
| 9 | Emergency stop switch adjusting bracket 100*60*44 | 27200174121 | 1 |
| 10 | Emergency stop switch ZB2BS54C+ZB2BZ101C | 4130705741 | 1 |
| 11 | Dumping brake rocker switch 171000101 | 4130713037 | 1 |
| 12 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
| 13 | Nut GB6170-M8EpZn-8 | 4013000033 | 4 |
| 14 | Pressure transducer | 4130712795 | 3 |
| 15 | Pressure transducer | 4130713641 | 1 |
| 16 | Parking pressure switch | 4130712793 | 1 |
| 17 | Temperature sensor httx | 4130713013 | 3 |
| 18 | Large circle warning light – magnetic suction | 4130712979 | 1 |
| 19 | Bolt GB5783-M8*25flznyc-8.8-480 | 4011010743 | 2 |
| 20 | Washer GB97.1-8flZnyc-300HV-480 | 4015010280 | 2 |
| 21 | Support | 27130114201 | 1 |
| 22 | Screw GB818-M5*10EpZn-4.8 | 4014000023 | 5 |
| 23 | Sheath LGB313-6*32 | 4043001111 | 2 |
| 24 | Washer GB97.1-5EpZn-300HV | 4015000110 | 5 |
| 25 | Fuel level sensor 104402701 | 4130712982 | 1 |
| 26 | Contact moduele with base ZB2BZ101C | 4130703636 | 1 |
| 27 | Reverse switch bracket 120*66*80 | 27200174131 | 1 |
| 28 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 6 |
| 29 | Washer GB97.1-10EpZn-300HV | 4015000162 | 6 |
| 30 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
