LGMG MT95H Mine Truck – Engine system – A0100-2701011460
Category: Mine Truck > MT95H > M095HHE02
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-18EpZn-300HV | 4015000182 | 6 |
| 2 | Support | 27010114651 | 1 |
| 3 | Bolt GB5785-M14*1.5*100flZnyc-12.9-480 | 4011010581 | 8 |
| 4 | BOLT GB6185.2-M14*1.5FLZNYC-10-480 | 4110001648 | 9 |
| 5 | Engine RR shock absorber AZ9925590360 | 4190002177 | 2 |
| 6 | Bolt GB5786-M18*1.5*40EpZn-12.9 | 4011010224 | 4 |
| 7 | ENGINE LEFT REAR FRAME | 27010114711 | 1 |
| 8 | ENGINE RIGHT REAR FRAME | 27010114791 | 1 |
| 9 | Plate | 27010114811 | 2 |
| 10 | Support | 27010114901 | 1 |
| 11 | Bolt GB5783-M16*65flZnyc-12.9-480 | 4011010552 | 3 |
| 12 | Pin | 27010114171 | 2 |
| 13 | Nut GB6185.1-M24EpZn-10 | 4013010140 | 2 |
| 14 | Beam | 27010114871 | 1 |
| 15 | Auxiliary support shock absorber 44003-13 | 4190001505 | 2 |
| 16 | Damper plate | 27050103881 | 4 |
| 17 | Bolt GB5782-M16*70flZnyc-12.9-480 | 4011010615 | 2 |
| 18 | SHIM | 27010114931 | 3 |
| 19 | SHIM | 27010114941 | 3 |
| 20 | Nut GB6170-M16flZnyc-12-480 | 4013010254 | 4 |
| 21 | Bolt GB5782-M16*130flZnyc-12.9-480 | 4011010567 | 2 |
| 22 | Nut GB6185.1-M16flZnyc-12-480 | 4013010251 | 10 |
| 23 | Support | 27010114921 | 1 |
| 24 | Engine assy MC13.54 | 4110002120 | 1 |
| 25 | Bolt GB5783-M12*75EpZn-8.8 | 4011000333 | 1 |
| 26 | Washer GB97.1-12EpZn-300HV | 4015000168 | 5 |
| 27 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 5 |
| 28 | Bolt GB5782-M14*75flZnyc-12.9-480 | 4011010600 | 1 |
| 29 | Bolt GB5782-M12*65EpZn-8.8 | 4011000261 | 2 |
| 30 | Bolt GB5782-M12*60EpZn-8.8 | 4011000260 | 2 |
| 31 | Bolt GB5782-M16*80flZnyc-12.9-480 | 4011010614 | 10 |
| 32 | Bolt GB5783-M16*45flZnyc-12.9-480 | 4011010621 | 12 |
| 33 | Washer GB97.1-16flZnyc-300HV-480 | 4015010287 | 10 |
| 34 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 1 |
| 35 | Nut GB6170-M10EpZn-8 | 4013000007 | 1 |
| 36 | Washer GB97.1-10EpZn-300HV | 4015000162 | 1 |
| 37 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 1 |
| 38 | Nut GB6170-M8EpZn-8 | 4013000033 | 1 |
| 39 | Washer GB96.1-8EpZn-300HV | 4015000256 | 1 |
| 40 | Bracket 1 | 27100103561 | 1 |
| 41 | Clamp | 26370001911 | 1 |
| 42 | Seat | 27010114861 | 1 |
| 43 | Bolt GB5783-M16*60flZnyc-12.9-480 | 4011010570 | 7 |
| 44 | Support | 27010114611 | 1 |
| 45 | Bolt GB5786-M14*1.5*40flZnyc-12.9-480 | 4011010551 | 8 |
| 46 | No longer used | 4015010281 | 17 |
| 47 | Engine FR shock absorber AZ9925590270 | 4190002176 | 2 |
| 48 | Bolt GB5785-M18*1.5*70flZnyc-12.9-480 | 4011010497 | 2 |
