LGMG RTH100 2025 – Emergency steering assy – H6000-2760000473.S1B
Category: 2025 > RTH100 > R1000Y3A0A238
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Single-pipe clamp 12 | 27600002361 | 2 |
| 2 | Bolt GB5783-M10*25flznyc-8.8-480 | 4011010722 | 2 |
| 3 | Washer GB96.1-10flZnyc-300HV-480 | 4015010278 | 7 |
| 4 | Pipe wldmt | 27600004741 | 1 |
| 5 | Straight reducer fitting red18/12lomdcf | 4120716180 | 1 |
| 6 | Bolt GB5783-M10*30flznyc-8.8-480 | 4011010707 | 1 |
| 7 | Nut GB6170-M10flZnyc-8-480 | 4013010289 | 3 |
| 8 | L-bracket 90*55*4 | 27600002981 | 1 |
| 9 | Cable tie 14400342 | 4130703098 | 1 |
| 10 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 1 |
| 11 | Pipe weldment | 27600002861 | 1 |
| 12 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 7 |
| 13 | Relief valve installation | 27600003781 | 1 |
| 14 | Bolt GB5783-M10*20flZnyc-8.8-480 | 4011010748 | 7 |
| 15 | Bracket 170*65*100 | 27600003811 | 1 |
| 16 | Tie assy 30 | 27250102471 | 1 |
| 17 | Bracket | 27620002681 | 1 |
| 18 | Combination joint LGB143-02616 | 4041001006 | 1 |
| 19 | Hose F681CACA181810-500 | 4120713597 | 1 |
| 20 | Bolt GB5783-M10*50flZnyc-8.8-480 | 4011010976 | 2 |
| 21 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 2 |
| 22 | Pipe weldment | 27600002951 | 1 |
| 23 | Power unit assy | 27600003791 | 1 |
| 24 | Bolt GB5782-M6*55flZnyc-8.8-480 | 4011010920 | 4 |
| 25 | Nut GB6170-M6flZnyc-8-480 | 4013010293 | 4 |
| 26 | Washer GB96.1-6flZnyc-300HV-480 | 4015010296 | 4 |
| 27 | Cover plate TL-G3 | 4120713171 | 2 |
| 28 | Pipe clamp TLPG-320 | 4120704816 | 2 |
| 29 | L-bracket 104*30*4 | 27600003741 | 1 |
| 30 | L-bracket 106*30*4 | 27600004721 | 1 |
| 31 | Spacer 150*30*10 | 27100146921 | 1 |
| 32 | Hose f487ceca101006-1160-pg | 4120716416-001 | 1 |
| 33 | Tube clamp TLPG12-320 | 4120711325 | 2 |
| 34 | Pipe weldment | 27600002871 | 1 |
| 35 | Bolt GB5783-M8*40flZnyc-8.8-480 | 4011010726 | 2 |
| 36 | Nut GB6170-M8flznyc-8-480 | 4013010291 | 2 |
| 37 | Washer GB96.1-8flZnyc-300HV-480 | 4015010289 | 2 |
| 38 | Bracket 30*70*105 | 27600003821 | 2 |
