LGMG MT60 Mine Truck – Transmission anchorage assy – C0502-2705010521
Category: Mine Truck > MT60 > M0600WE11
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M16*45EpZn-8.8 | 4011000205 | 2 |
| 2 | Damper plate | 27050103881 | 4 |
| 3 | Auxiliary support shock absorber 44003-13 | 4190001505 | 2 |
| 4 | Intermediate shoe | 27050104121 | 1 |
| 5 | Bolt GB5782-M16*130flZnyc-12.9-480 | 4011010567 | 2 |
| 6 | Bolt GB5783-M16*65flZnyc-12.9-480 | 4011010552 | 8 |
| 7 | Left anchorage | 27050104563 | 1 |
| 8 | Washer GB97.1-16flZnyc-300HV-480 | 4015010287 | 6 |
| 9 | Nut GB6185.1-M16flZnyc-12-480 | 4013010251 | 8 |
| 10 | Nut GB6170-M16flZnyc-12-480 | 4013010254 | 8 |
| 11 | No longer used | 4015000305 | 2 |
| 12 | UPPER CONNECT PLATE ASSEMBLY | 27050104421 | 1 |
| 13 | TUNING WASHER | 27050104201 | 2 |
| 14 | Adjusting gasket | 27050103661 | 2 |
| 15 | Adjusting gasket | 27050103671 | 2 |
| 16 | Right anchorage | 27050104603 | 1 |
| 17 | Bolt GB5783-M16*80flZnyc-12.9-480 | 4011010568 | 2 |
| 18 | Washer 16 | 27150105311 | 4 |
