LGMG Mine Truck Mine Truck – Warning light optional module assy – K1300-2713011811
Category: Mine Truck > Mine Truck > M0860WF00
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Alarm lamp 2RL-009506-51 | 4130000669 | 1 |
| 2 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 2 |
| 3 | Support | 27130114201 | 1 |
| 4 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
| 5 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 6 | P dome light wire | 27130118121 | 1 |
| 7 | Screw GB818-M4*16EpZn-4.8 | 4014000087 | 3 |
| 8 | Washer GB97.1-4EpZn-300HV | 4015000135 | 3 |
| 9 | Warning ceiling lamp rocker switchJK939C | 4130000667 | 1 |
