LGMG CMT66A 2025 – Absorber installation assy – G1201-2712017290
Category: 2025 > CMT66A > C066AW3E0A021
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Shock absorber | 27120104171 | 2 |
| 2 | Bolt GB5785-M16*1.5*90flZnyc-12.9-480 | 4011010558 | 2 |
| 3 | Washer | 27120104442 | 4 |
| 4 | Bolt 5783-M20*1.5*70flZnyc-12.9-480 | 4011011450 | 4 |
| 5 | Plate | 27120121081 | 2 |
| 6 | Bolt GB5785-M16*1.5*130flZnyc-12.9-480 | 4011010557 | 2 |
| 7 | Washer GB97.1-16EpZn-300HV | 4015000181 | 2 |
| 8 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 4 |
| 9 | Washer GB96.1-16EpZn-300HV | 4015000279 | 8 |
| 10 | Upper bracket | 27120172821 | 2 |
| 11 | Backing plate | 27120107161 | 4 |
| 12 | Nut GB6185.1-M14flZnyc-12-480 | 4013010253 | 8 |
| 13 | Washer GB97.1-14EpZn-300HV | 4015000177 | 8 |
| 14 | Bolt GB5783-M14*50flZnyc-12.9-480 | 4011010549 | 8 |
