LGMG CMT106 2025 – Dryer & spiral pipe assy – J1001-2710014254.S1A
Category: 2025 > CMT106 > C1060Y3E0A101
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Joint m12-m12 | 27100104301 | 1 |
| 2 | Plate | 27100113271 | 1 |
| 3 | Bolt GB5786-M12*1.5*30EpZn-8.8 | 4011000317 | 3 |
| 4 | Washer GB97.1-12EpZn-300HV | 4015000168 | 3 |
| 5 | Air Handling unit | 4120001482 | 1 |
| 6 | M22-m22 rectangular connector | 27100100691 | 1 |
| 7 | Washer JB982-22 | 4015000092 | 1 |
| 8 | Wired hose | 27100107941 | 1 |
| 9 | Pipe assembly | 27100113261 | 1 |
| 10 | Rubber sleeve | 27100124781 | 1 |
| 11 | Dryer bracket | 27100142551 | 1 |
| 12 | BOLT GB5782-M14*55EpZn-8.8 | 4011000067 | 2 |
| 13 | Washer GB97.1-14EpZn-300HV | 4015000177 | 2 |
| 14 | Nut GB6170-M14EpZn-8 | 4013000013 | 2 |
| 15 | Bolt GB5782-M10*55EpZn-8.8 | 4011000049 | 2 |
| 16 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 17 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 18 | Bolt GB5782-M16*60flZnyc-12.9-480 | 4011010623 | 1 |
| 19 | Washer GB97.1-16flZnyc-300HV-480 | 4015010287 | 1 |
| 20 | Nut GB6185.1-M16flZnyc-12-480 | 4013010251 | 1 |
| 21 | Washer JB982-12 | 4015000327 | 1 |
| 22 | Rubber clip | 27100108841 | 2 |
| 23 | Bolt GB5782-M10*50flZnyc-10.9-480 | 4011011195 | 2 |
| 24 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 2 |
| 25 | Nut GB6170-M10flZnyc-8-480 | 4013010289 | 2 |
