LGMG MT50 2025 – Dryer & spiral pipe assy – J1001-2710015527.S1A
Category: 2025 > MT50 > M0500Y3E0M301
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Spiral pipe bracket 310*50*92.5 | 27100140501 | 1 |
| 2 | Rubber clip | 27100108841 | 2 |
| 3 | Plate | 27100108872 | 1 |
| 4 | Bolt GB5782-M10*55EpZn-8.8 | 4011000049 | 2 |
| 5 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 2 |
| 6 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 2 |
| 7 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 8 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 9 | Bolt GB5786-M16*1.5*55EpZn-8.8 | 4011000698 | 1 |
| 10 | Washer GB97.1-16EpZn-300HV | 4015000181 | 2 |
| 11 | Air Handling unit | 4120001086 | 1 |
| 12 | Nut GB6170-M16EpZn-8 | 4013000016 | 2 |
| 13 | Bolt GB5786-M16*1.5*50EpZn-8.8 | 4011000244 | 1 |
| 14 | Dryer bracket wldmt | 27100137752 | 1 |
| 15 | Bolt GB5786-M12*1.5*30EpZn-8.8 | 4011000317 | 3 |
| 16 | Washer GB97.1-12EpZn-300HV | 4015000168 | 3 |
| 17 | M22-m22 rectangular connector | 27100100691 | 1 |
| 18 | Washer JB982-22 | 4015000092 | 1 |
| 19 | Combination joint LGB143-02213 | 4041001156 | 2 |
| 20 | Steel braided hose-220 (high resilience) | 27100131041 | 1 |
| 21 | Spiral steel pipe 16*1.5 | 27100140511 | 1 |
