LGMG MT50 2025 – Radiator lg03-srq-025 – A0700-4190716704
Category: 2025 > MT50 > M0500Y3E0M108
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Hexagonal flange face bolt gb5789-m10 * 25 | 4110708201011 | 16 |
| 2 | Bolt gb/t5789 (m8*25-10.9) | 4110706112009 | 10 |
| 3 | Washer GB97.1-8flZnyc-300HV-480 | 4015010280 | 10 |
| 4 | Bolt gb5789 | 4110708353003 | 8 |
| 5 | Bolt gb5789-m12*25flznyc-10.9-480 | 4011011544 | 2 |
| 6 | Hexagonal flange face bolt gb5789-m10 * 20 | 4110708201010 | 12 |
| 7 | Rubber pad | 4110708086208 | 8 |
| 8 | Shock pad | 4110708353004 | 4 |
| 9 | Framework under | 4110707272001 | 1 |
| 10 | Left frame | 4110707272002 | 2 |
| 11 | Right frame | 4110707272003 | 1 |
| 12 | Water radiator | 4110707272004 | 4 |
| 13 | Charge air cooler | 4110708353001 | 1 |
| 14 | The framework | 4110707272006 | 1 |
| 15 | Fan shroud | 4110708353002 | 1 |
| 16 | Rod mounting plate | 4110707272008 | 1 |
| 17 | Mounting bracket | 4110707272009 | 2 |
