LGMG Off-Highway Dump Truck 2021 – Drive shaft assy – F0900-4110000822
Category: 2021 > Off-Highway Dump Truck > MT50 > M0500WEA2
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Flange york 6204101111 | 4110000822001 | 2 |
| 2 | Cross shaft 620-62160 | 4110000822002 | 2 |
| 3 | Jump ring 362-2201-02 | 4110000822003 | 8 |
| 4 | Spline shaft fork 6204101113 | 4110000822004 | 1 |
| 5 | Grease nipple M6 | 4030000535 | 1 |
| 6 | Sheath pipe 3954100483-B | 4110000822005 | 1 |
| 7 | Spline hub 6201301113 | 4110000822006 | 1 |
| 8 | Shaft tube φ130*5 700QZ | 4110000822007 | 1 |
| 9 | Cardan fork 6201301301 | 4110000822008 | 1 |
