LGMG Off-Highway Dump Truck 2024 – Air filter assembly – A1801-2718011114.S1A
Category: 2024 > Off-Highway Dump Truck > MT106H > M106HW3A0M380
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Air filter pipe 215*6*833 | 27180111152 | 1 |
| 2 | Butterfly spring clamp φ93-φ118 | 4190708166 | 3 |
| 3 | Connecting steel pipe 100*1.5*835 | 27180111162 | 1 |
| 4 | Engine air intake pipe 110*5*480 | 27180111172 | 1 |
| 5 | Butterfly spring clamp φ25-φ45 | 4190708159 | 4 |
| 6 | Connect pipe35*5*154 | 27180111211 | 1 |
| 7 | Pipe | 27180110931 | 1 |
| 8 | Pipe | 27180110911 | 1 |
| 9 | Steel pipe supt | 27030131172 | 2 |
| 10 | Rubber support | 27030122161 | 4 |
| 11 | Maintenance-free air filter assy K160047 | 4190707575 | 1 |
| 12 | Plate | 27030122151 | 2 |
| 13 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 8 |
| 14 | BOLT GB16674-M10*70EpZn-8.8 | 4011000476 | 4 |
| 15 | Bolt GB16674.1-M8*16flZnyc-8.8-480 | 4011010964 | 2 |
| 16 | Exhaust pipe strap | 27240102332 | 2 |
| 17 | Plate 150*40*15 | 27180111111 | 2 |
| 18 | Air filter bracket 180*110*80 | 27180111181 | 1 |
| 19 | Bolt GB5782-M10*70EpZn-8.8 | 4011000051 | 2 |
| 20 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
| 21 | Air filter bracket 180*120*110 | 27180111261 | 1 |
| 22 | Air clean supporting | 27180109571 | 1 |
| 23 | Bolt GB5782-M10*35EpZn-8.8 | 4011010164 | 2 |
| 24 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
| 25 | Nut GB6170-M10EpZn-8 | 4013000007 | 8 |
| 26 | Nut seat NG8 | 4120000194 | 1 |
| 27 | Clip spring NG8 | 4120000196 | 1 |
| 28 | Elastic element NG8 | 4120000197 | 1 |
| 29 | Pipe | 27110105682 | 1 |
| 30 | Bolt GB5782-M12*110EpZn-8.8 | 4011000262 | 6 |
| 31 | Washer GB96.1-12EpZn-300HV | 4015000186 | 12 |
| 32 | Washer GB97.1-12EpZn-300HV | 4015000168 | 8 |
| 33 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 8 |
| 34 | Bolt GB5782-M12*75EpZn-8.8 | 4011000874 | 6 |
| 35 | Wire | 27200108491 | 1 |
| 36 | Butterfly spring clamp φ210-φ232 | 4190708175 | 1 |
