LGMG Off-Highway Dump Truck 2023 – Eddy current electrical module – K2001-2720015484.S1A
Category: 2023 > Off-Highway Dump Truck > CMTE106H > C106HE0A0A403
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 4 |
| 2 | Power cable p50*400 | 27200155331 | 1 |
| 3 | Power cable p50*4550 | 27200155341 | 1 |
| 4 | Power cable p50*850 | 27200155351 | 1 |
| 5 | Bolt GB5783-M10*45flZnyc-10.9-480 | 4011011509 | 1 |
| 6 | Washer GB862.2-10-65Mn | 4015010586 | 2 |
| 7 | Double sack wedge lock washer HF10 | 4190708409 | 4 |
| 8 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 1 |
| 9 | Support | 27620003431 | 5 |
| 10 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 5 |
| 11 | Washer GB97.1-10EpZn-300HV | 4015000162 | 9 |
| 12 | Nut GB6170-M10EpZn-8 | 4013000007 | 11 |
| 13 | Holder | 27200142321 | 1 |
| 14 | Holder | 27200148311 | 1 |
| 15 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 4 |
| 16 | Washer GB97.1-8-300HV | 4015000315 | 8 |
| 17 | Nut GB6170-M8-8 | 4013000162 | 4 |
