LGMG Mine Truck 2026 – Service brake assy – J1001-2710014721.S1D
Category: 2026 > Mine Truck > MTH116 > C1160Y3A0A006
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | ABS Solenoid valve 35503000040 | 4120706434 | 2 |
| 2 | Bolt gb16674.1-m8*110flznyc-8.8-480 | 4011012004 | 4 |
| 3 | Washer GB96.1-8flZnyc-300HV-480 | 4015010289 | 6 |
| 4 | Nut GB6170-M8flznyc-8-480 | 4013010291 | 4 |
| 5 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 4 |
| 6 | Nut M18 | 4120000230 | 1 |
| 7 | Thin nut M16*1.5 | 4120000234 | 2 |
| 8 | Bracket 1 | 27100103561 | 1 |
| 9 | Battery box assy | 27100147271 | 1 |
| 10 | Bolt gb5789-m16*1.5*150flznyc-12.9-480 | 4011011954 | 1 |
| 11 | Nut seat | 27110107601 | 3 |
| 12 | Nut gb6187.2-m16*1.5flznyc-12-480 | 4013010635 | 6 |
| 13 | Bolt gb5789-m16*1.5*140flznyc-12.9-480 | 4011011953 | 5 |
| 14 | Bolt GB16674.1-M8*25flZnyc-8.8-480 | 4011010994 | 5 |
| 15 | Nut GB6177.1-M8flZnyc-8-480 | 4013010386 | 5 |
| 16 | Cable tie HS-J117 | 4130704969 | 2 |
| 17 | Plate | 27010113352 | 2 |
| 18 | Installation assembly | 27100117051 | 1 |
| 19 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 7 |
| 20 | Grommet strip assy | 27100145061 | 2 |
| 21 | Ebs one-channel module | 27100145011 | 1 |
| 22 | Transition joint assy NG12-M16*1.5 | 4120705999 | 3 |
| 23 | Grommet strip 240*109*22 | 27100145221 | 2 |
| 24 | Bolt GB16674.1-M12*40flZnyc-8.8-480 | 4011011424 | 4 |
| 25 | Nut gb6177.1-m12flznyc-8-480 | 4013010621 | 10 |
| 26 | Four-circuit protection valve assy | 27100145051 | 1 |
| 27 | T-connector m14-npt1/8-m14 | 27100106991 | 1 |
| 28 | Joint GZ08LCF | 4120707133 | 1 |
| 29 | Shuttle valve assy | 27100145001 | 2 |
| 30 | Grommet strip assy | 27100147351 | 2 |
| 31 | Connecter | 27100114051 | 4 |
| 32 | Combination joint LGB143-02213 | 4041001156 | 2 |
| 33 | Elec brake pedal assy | 4120706429 | 1 |
| 34 | Combination joint LGB143-01406 | 4041001047 | 1 |
| 35 | Grommet strip assy | 27100147341 | 2 |
| 36 | Air hose bracket assy 01 | 27100147311 | 1 |
| 37 | Redudant braking valve assy | 27100147801 | 1 |
| 38 | Ebs two-channel module | 27100147221 | 1 |
| 39 | Air compressor assy | 27100147491 | 1 |
| 40 | Brake air line assy | 27100147331 | 1 |
| 41 | Straight bulkhead joint NG6/2-M16*1.5 | 4120000233 | 2 |
| 42 | Bolt GB16674.1-M12*30flZnyc-8.8-480 | 4011010713 | 6 |
| 43 | Bolt GB16674.1-M10*25flZnyc-8.8-480 | 4011011015 | 1 |
| 44 | M14-NPT1/8 bulkhead union | 27100106211 | 1 |
| 45 | Plate 350*286*60 | 27100153292 | 1 |
| 46 | Plate 388*330*83 | 27100151842 | 1 |
| 47 | Grommet 60*46*10 | 27100151861 | 1 |
| 48 | Air pipe gpu-13-i-880-sg | 27100107441 | 2 |
| 49 | JOINT LGB143-11810 | 4041001464 | 4 |
| 50 | Joint | 27100122611 | 2 |
| 51 | CONNECTOR | 27100100661 | 2 |
| 52 | Washer JB982-16 | 4015000141 | 6 |
