LGMG MT76 Mine Truck – System – K2000-2720010527002
Category: Mine Truck > MT76 > MT76
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Frame | 27200104441 | 2 |
| 2 | LED Floodlamp SM6272 | 4130000610 | 2 |
| 3 | LED Combination lamp | 4130000617 | 2 |
| 4 | Heel | 27200103872 | 2 |
| 5 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 8 |
| 6 | Cargo lifting switch XJK-010-09 | 4130000641 | 1 |
| 7 | String casing | 27140105021 | 1 |
| 8 | Parking pressure switch 0.55MPa | 4130000006 | 1 |
| 9 | Cable protector | 27140108701 | 2 |
| 10 | Electromagnetic valve air pressure switch 0.3MPa | 4130000007 | 1 |
| 11 | Farme wire | 27200105631 | 1 |
| 12 | Left lamp guard | 27200102311 | 1 |
| 13 | Guard | 27140105031 | 1 |
| 14 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 2 |
| 15 | LEDWork lamp SM6502 | 4130000659 | 2 |
| 16 | Right lamp guard | 27200102321 | 1 |
| 17 | Single rod fuel sensor | 4130000616 | 1 |
| 18 | Screw GB818-M5*12EpZn-4.8 | 4014000048 | 5 |
| 19 | Washer GB97.1-5EpZn-300HV | 4015000110 | 5 |
| 20 | Reverse buzzer DDB101-LG | 4130000294 | 1 |
