LGMG Off-Highway Dump Truck 2024 – Seat assembly – G1201-2712017778.S1B
Category: 2024 > Off-Highway Dump Truck > MTE106H > C106HE0A0A901
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27120177801 | 1 |
| 2 | Seat | 27120177811 | 2 |
| 3 | Bolt m24*3*470 | 27120118111 | 6 |
| 4 | Washer gb1230-24flznyc-45-480 | 4015010630 | 6 |
| 5 | Self-locking nut with the shoulder | 27120103611 | 6 |
| 6 | Seat | 27120177791 | 4 |
| 7 | Bolt GB5782-M16*125flZnyc-12.9-480 | 4011010682 | 8 |
| 8 | Washer GB1230-16flZnyc-45-480 | 4015010563 | 16 |
| 9 | Nut GB6185.1-M16flZnyc-12-480 | 4013010251 | 8 |
