LGMG Off-Highway Dump Truck 2023 – Engine compartment mounting assembly – L3601-2736015821
Category: 2023 > Off-Highway Dump Truck > MT86H > M086HW2E0M008
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Narrow body nacelle front mask assembly | 27360158201 | 1 |
| 2 | Sealing sheath LGB346-3*30*28 | 4030100318 | 3 |
| 3 | Cover | 27360127271 | 2 |
| 4 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 4 |
| 5 | Bolt GB5783-M12*60EpZn-8.8 | 4011000284 | 2 |
| 6 | Washer GB96.1-12EpZn-300HV | 4015000186 | 12 |
| 7 | Nut GB6185.1-M12EpZn-8 | 4013010120 | 16 |
| 8 | Plate | 27360138171 | 2 |
| 9 | L-shaped pull plate 915*40*20 | 27360158221 | 1 |
| 10 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 2 |
| 11 | Narrow body hood on-frame welding | 27360158231 | 1 |
| 12 | Support108*40*39 | 27360158371 | 3 |
| 13 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 8 |
| 14 | Washer GB97.1-12EpZn-300HV | 4015000168 | 20 |
| 15 | Bolt GB5783-M12*45EpZn-8.8 | 4011000207 | 4 |
| 16 | Plate80*59*40 | 27360158381 | 3 |
| 17 | Pin GB91-3.2*18flZnyc-Q235A-480 | 4016010166 | 3 |
| 18 | Pin GB882-B8*45*3.2EpZn-35 | 4016010271 | 3 |
| 19 | Rubber handle | 4190708784 | 3 |
| 20 | Engine cover | 27360156091 | 1 |
| 21 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 18 |
| 22 | Washer GB96.1-8EpZn-300HV | 4015000256 | 18 |
| 23 | Right column handrail welding | 27360158241 | 1 |
| 24 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 25 | Bolt GB5783-M10*12-8.8 | 4011000630 | 2 |
| 26 | Plate | 27360138091 | 1 |
| 27 | Plate | 27360156081 | 1 |
