LGMG ？？2？？？？？？？？？？？o Hydrualic Excavator 2024 – Traveling motor MSF-340VP-337/228 – F0700-4120708281
Category: 2024 > ？？2？？？？？？？？？？？o Hydrualic Excavator > ME106 > E10600P3A004
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | O-ring 95113-02100 | 4120708281010 | 1 |
| 2 | O-ring 21001-00182 | 4120708281011 | 1 |
| 3 | Snap ring 95712-01200 | 4120708281012 | 1 |
| 4 | Snap ring 95712-01800 | 4120708281013 | 2 |
| 5 | Snap ring 95713-02100 | 4120708281014 | 2 |
| 6 | Spring B0111-13072 | 4120708281015 | 1 |
| 7 | Plug 20461-52406 | 4120708281016 | 1 |
| 8 | O-ring 95113-01800 | 4120708281009 | 2 |
| 9 | Plug 20461-42414 | 4120708281017 | 1 |
| 10 | Valve 21961-60301 | 4120708281018 | 2 |
| 11 | O-ring 95113-01400 | 4120708281001 | 2 |
| 12 | Spring 21961-60412 | 4120708281019 | 2 |
| 13 | Plug 21961-95014 | 4120708281020 | 2 |
| 14 | O-ring 95113-02900 | 4120708281021 | 2 |
| 15 | Plug 20461-32422 | 4120708281022 | 6 |
| 16 | O-ring 95113-01100 | 4120708281023 | 6 |
| 17 | Shaft B0441-02012 | 4120708281024 | 1 |
| 18 | Swash plate B0111-74046 | 4120708281025 | 1 |
| 19 | Steel ball 20461-69205 | 4120708281026 | 2 |
| 20 | Spring B0111-13073 | 4120708281027 | 2 |
| 21 | Bearing B0141-69003 | 4120708281028 | 1 |
| 22 | Spring seat 2196-40504 | 4120708281002 | 2 |
| 23 | Bearing B0141-69004 | 4120708281029 | 1 |
| 24 | Clamp B0111-18039 | 4120708281030 | 1 |
| 25 | Pin 20461-70802 | 4120708281031 | 1 |
| 26 | Spring 20461-61306 | 4120708281032 | 9 |
| 27 | Friction plate B0441-96007 | 4120708281033 | 2 |
| 28 | Disc 20461-69503 | 4120708281034 | 5 |
| 29 | Friction plate B0441-96008 | 4120708281035 | 4 |
| 30 | Piston B0441-94007 | 4120708281036 | 1 |
| 31 | O-ring 20461-75201 | 4120708281037 | 1 |
| 32 | Snap ring B0141-51002 | 4120708281038 | 1 |
| 33 | Spring 21961-60402 | 4120708281003 | 2 |
| 34 | O-ring 20461-65213 | 4120708281039 | 1 |
| 35 | Snap ring 20461-65104 | 4120708281040 | 1 |
| 36 | Spring B0111-13074 | 4120708281041 | 10 |
| 37 | Pin 20361-40845 | 4120708281042 | 4 |
| 38 | Oil seal B0141-21038 | 4120708281043 | 1 |
| 39 | O-ring 95123-26000 | 4120708281044 | 4 |
| 40 | O-ring 95113-01000 | 4120708281045 | 4 |
| 41 | Plug 21961-95025 | 4120708281046 | 2 |
| 42 | O-ring 95113-02400 | 4120708281047 | 2 |
| 43 | Bolt 92703-18500 | 4120708281048 | 9 |
| 44 | Spring seat B0441-14008 | 4120708281004 | 2 |
| 45 | COVER assy B0853-06006 | 4120708281005 | 2 |
| 46 | O-ring 95123-04000 | 4120708281006 | 1 |
| 47 | Safety valve assy B0853-01110 | 4120708281007 | 2 |
| 48 | O-ring 95113-001200 | 4120708281008 | 1 |
| 49 | O-ring 95113-01800 | 4120708281009 | 1 |
