LGMG CMT96A 2025 – Frame assy – I1402-2714025102.S1A
Category: 2025 > CMT96A > C096AY3E0A008
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5786-M16*1.5*60-12.9 | 4011010219 | 10 |
| 2 | Nut GB6185.2-M16*1.5-12 | 4013010222 | 10 |
| 3 | Washer GB97.1-16flZnyc-300HV-480 | 4015010287 | 4 |
| 4 | Connecting rod | 27140123531 | 2 |
| 5 | Spacer 30*6.5*34 | 27140196201 | 2 |
| 6 | Traction hook | 27140196141 | 2 |
| 7 | Bolt GB5786-M16*1.5*45flZnyc-12.9-480 | 4011010535 | 2 |
| 8 | Fr protection grill wldmt | 27140236261 | 1 |
| 9 | Bolt GB5785-M16*1.5*75flZnyc-12.9-480 | 4011010587 | 2 |
| 10 | Frame | 27140251031 | 1 |
| 11 | Walkway brackets installation | 27140263581 | 1 |
| 12 | Frame | 27140173281 | 1 |
| 13 | Frame | 27140173251 | 1 |
| 14 | Bolt GB5786-M16*1.5*50flZnyc-12.9-480 | 4011010555 | 12 |
| 15 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 30 |
| 16 | Bolt GB5785-M16*1.5*80flZnyc-12.9-480 | 4011010592 | 18 |
| 17 | Washer GB1230-16flZnyc-45-480 | 4015010563 | 16 |
| 18 | Frame | 27140173261 | 1 |
