LGMG ？？2？？？？？？？？？？？o Hydrualic Excavator 2024 – Mid framework assy – M3301-2633000422
Category: 2024 > ？？2？？？？？？？？？？？o Hydrualic Excavator > ME105 > E10500P3A007
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 26330003153 | 4 |
| 2 | Door | 26330004012 | 1 |
| 3 | Plate | 26330004032 | 1 |
| 4 | Framework | 26330004042 | 1 |
| 5 | Gas spring 10-190-510（B-B）400 | 4190708096 | 1 |
| 6 | Gas spring B10-190-510（B-B）400 | 4190708097 | 1 |
| 7 | Hood door lock assy NBS504LG-2G | 4190708901 | 2 |
| 8 | Washer GB97.1-5flZnyc-300HV-480 | 4015010283 | 4 |
| 9 | Washer 12.5*32*4.5 | 4190707653 | 20 |
| 10 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 8 |
| 11 | Rubber block | 4190705245 | 6 |
| 12 | Washer GB97.1-12flZnyc-300HV-480 | 4015010340 | 16 |
| 13 | Nut GB6170-M8flZnyc-10-480 | 4013010540 | 6 |
| 14 | Bolt GB5783-M12*30flZnyc-10.9-480 | 4011010866 | 36 |
| 15 | Plate | 4190705599 | 4 |
| 16 | Buffer block | 4110703512 | 2 |
| 17 | Nut GB6185.1-M5flZnyc-8-480 | 4013010397 | 4 |
| 18 | Plate | 26330000851 | 1 |
| 19 | Plate | 26330001402 | 1 |
| 20 | Door | 26330003003 | 1 |
| 21 | Door | 26330003043 | 1 |
| 22 | Door | 26330003082 | 1 |
