LGMG Off-Highway Dump Truck 2024 – Chassis middle electrical module – K2000-2720014036
Category: 2024 > Off-Highway Dump Truck > CMT66A > C066AW3E0A004
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Itt plate | 27200107441 | 2 |
| 2 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 3 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 2 |
| 4 | Stop lamp switch YK209KLA | 4130000492 | 2 |
| 5 | Air pressure sensor YG2221SLN | 4130000990 | 2 |
| 6 | String casing | 27140105021 | 3 |
| 7 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 8 | Parking pressure switch 0.55MPa | 4130000006 | 1 |
| 9 | Electromagnetic valve air pressure switch 0.3MPa | 4130000007 | 1 |
