LGMG Mine Truck 2026 – Battery thermal mgnt external line assy – A6400-2764001583.S1A
Category: 2026 > Mine Truck > RTH100 > R1000Y3A0A243
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Clamp R-D16-M10 | 4190707967 | 4 |
| 2 | Water tank 2.6L | 4190710291 | 1 |
| 3 | Clamp φ17-φ38 | 4190708280 | 9 |
| 4 | Reducing hose25-20*5*503 | 27640015841 | 1 |
| 5 | Bracket 100*75*4 | 27640015851 | 1 |
| 6 | BOLT | 4011011213 | 1 |
| 7 | Washer GB97.1-12flZnyc-300HV-480 | 4015010340 | 1 |
| 8 | Clamp R-D32-M10 | 4190707972 | 4 |
| 9 | Hose clamp JB8870-D20 | 4017000010 | 4 |
| 10 | Breather hose 8*3*868 | 27640015041 | 1 |
| 11 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 13 |
| 12 | Bolt GB5782-M10*65flZnyc-8.8-480 | 4011010729 | 5 |
| 13 | Plate 105*25*4 | 27640002521 | 2 |
| 14 | Breather hose 8*3*1160 | 27640015031 | 1 |
| 15 | Valve assembly | 27210103841 | 1 |
| 16 | Bracket 254*38*30 | 27640010751 | 1 |
| 17 | Hose 20*5*936 | 27640015861 | 1 |
| 18 | Bracket 50*40*4 | 27640009941 | 1 |
| 19 | Bracket 147*44*4 | 27640009961 | 1 |
| 20 | Pipe clamp R-D40-M10 | 4190707973 | 5 |
| 21 | Hose 25*5*1194 | 27640015881 | 1 |
| 22 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 33 |
| 23 | Hose 25*5*732 | 27640015891 | 1 |
| 24 | Bracket 74*73*4 | 27640009951 | 1 |
| 25 | Bracket 530*317*4 | 27640009911 | 1 |
| 26 | Bracket 452*40*30 | 27640010761 | 1 |
| 27 | Double hole R-type clamp R-D40*2-M10 | 4190707989 | 1 |
| 28 | Bracket 390*119*40 | 27640009931 | 1 |
| 29 | Hose clamp JB8870-D50 | 4017000009 | 1 |
| 30 | Bracket 50*30*25 | 27640000661 | 1 |
| 31 | Reducing hose 35-25*5-721 | 27640015871 | 1 |
| 32 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 44 |
| 33 | Bracket wldmt | 27640015111 | 1 |
| 34 | Washer GB96.1-10flZnyc-300HV-480 | 4015010278 | 3 |
| 35 | L-bracket 140*40*30 | 27640015001 | 1 |
| 36 | L-bracket 140*64*40 | 27640015011 | 1 |
| 37 | Bracket 105*30*4 | 27640003371 | 1 |
| 38 | Bolt GB5783-M10*25flznyc-8.8-480 | 4011010722 | 19 |
