LGMG MT50 Mine Truck – Parking brake assy – J1102-2711010192
Category: Mine Truck > MT50 > M0500WE60
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Elastic element NG6 | 4120000211 | 7 |
| 2 | Nut seat NG8 | 4120000194 | 5 |
| 3 | Elastic element NG8 | 4120000197 | 5 |
| 4 | Clip spring NG8 | 4120000196 | 5 |
| 5 | Air reservoir bracket | 27110101221 | 1 |
| 6 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 4 |
| 7 | Air reservoir 30L（275） | 4120000142 | 1 |
| 8 | Hose clamp φ275-φ280 | 4120000178 | 2 |
| 9 | Drain valve | 4120000200 | 2 |
| 10 | Plug NG12-M22*1.5 | 4120000201 | 1 |
| 11 | Relay valve | 4120000137 | 1 |
| 12 | Fagging | 27140108681 | 2 |
| 13 | T-connector M14-M12-M14 | 27110101341 | 1 |
| 14 | Pressure switch block | 27110101381 | 1 |
| 15 | Reducing joint | 27110101891 | 1 |
| 16 | Button valve | 4120001046 | 1 |
| 17 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 2 |
| 18 | Washer GB97.1-6EpZn-300HV | 4015000207 | 2 |
| 19 | connector | 27110101371 | 1 |
| 20 | M14 Direct head | 27100101201 | 1 |
| 21 | PIPE | 27110101711 | 1 |
| 22 | Nut GB6170-M8EpZn-8 | 4013000033 | 10 |
| 23 | M14 Direct head | 27100101211 | 1 |
| 24 | Washer JB982-10 | 4015000140 | 2 |
| 25 | M12-M10-M14 | 27110101721 | 1 |
| 26 | NUT | 27110101731 | 1 |
| 27 | 30l reservoir bracket | 27110103491 | 1 |
| 28 | Air reservoir 20L | 4120000360 | 1 |
| 29 | Hose clamp φ246-φ250 | 4120000177 | 2 |
| 30 | Washer JB982-22 | 4015000092 | 2 |
| 31 | PLATE | 27110101601 | 1 |
| 32 | Dual way check valve | 4120000361 | 1 |
| 33 | Washer GB97.1-8EpZn-300HV | 4015000072 | 10 |
| 34 | Joint M22-M16 | 27110101561 | 1 |
| 35 | Thin nut M16*1.5 | 4120000234 | 1 |
| 36 | Joint M22-M12 | 27100104611 | 2 |
| 37 | Block | 27110101931 | 2 |
| 38 | Bolt GB5782-M8*45EpZn-8.8 | 4011000298 | 2 |
| 39 | Quadruple solenoid valve DF2664F | 4120000943 | 1 |
| 40 | Joint M12-M12 | 27110101331 | 3 |
| 41 | Washer JB982-12 | 4015000327 | 3 |
| 42 | Nut seat NG12 | 4120000190 | 9 |
| 43 | Clip spring NG12 | 4120000192 | 9 |
| 44 | Plate | 27100106031 | 1 |
| 45 | Elastic element NG12 | 4120000193 | 9 |
| 46 | Hand brake valve | 4120000134 | 1 |
| 47 | Bolt GB5782-M8*50EpZn-8.8 | 4011000223 | 2 |
| 48 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 6 |
| 49 | Plate | 27110102581 | 4 |
| 50 | Plate | 27110102591 | 4 |
| 51 | CLAMP | 27110102381 | 4 |
| 52 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 8 |
| 53 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 6 |
| 54 | Nut GB6170-M10EpZn-8 | 4013000007 | 20 |
| 55 | Washer GB97.1-10EpZn-300HV | 4015000162 | 20 |
| 56 | Nut seat NG6 | 4120000213 | 7 |
| 57 | Clip spring NG6 | 4120000212 | 7 |
