LGMG AT40 2025 – Diversion cartridge block assembly – M1601-2716013984.S1B
Category: 2025 > AT40 > A0400W3M0A114
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Tee EL22LOMDCF | 4120705586 | 1 |
| 2 | Straight joint GE22LR1/2EDOMDCF | 4120705644 | 1 |
| 3 | Combination joint LGB143-03019 | 4041001262 | 1 |
| 4 | Straight joint GE22LREDOMDCF | 4120705620 | 1 |
| 5 | Split flange LGB117-312551 | 4041000027 | 1 |
| 6 | O-ring GB3452.1-37.5*3.55G | 4030000029 | 1 |
| 7 | Screw GB70.1-M10*35flZnyc-10.9-480 | 4014010288 | 4 |
| 8 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 4 |
| 9 | Mounting bracket welding | 27160139851 | 1 |
| 10 | Bolt GB16674.1-M8*16flZnyc-8.8-480 | 4011010964 | 4 |
| 11 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 2 |
| 12 | Nut GB6177.1-M10flZnyc-8-480 | 4013010375 | 2 |
| 13 | Valve 11321173 | 4120713552 | 1 |
| 14 | Joint GE08LREDOMDCF | 4120001170 | 1 |
| 15 | Joint GE10LREDOMDCF | 4120001188 | 1 |
| 16 | Joint GE12LR1/2EDOMDCF | 4120001373 | 1 |
| 17 | Combination joint LGB143-01810 | 4041001063 | 1 |
