LGMG Off-Highway Dump Truck 2023 – Pressure limiting valve assy – J1101-2711011478.S1A
Category: 2023 > Off-Highway Dump Truck > RT100 > R1000W3A0M001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pressure limiting valve | 4120001472 | 1 |
| 2 | Pressure limiting valve bracket | 27110114791 | 1 |
| 3 | Bolt GB5782-M8*75flZnyc-8.8-480 | 4011010995 | 2 |
| 4 | Washer GB97.1-8EpZn-300HV | 4015000072 | 4 |
| 5 | Nut GB6170-M8EpZn-10 | 4013000031 | 2 |
| 6 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 2 |
| 7 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 8 | Transition joint M22*1.5/NG12 | 4120001552 | 2 |
