LGMG – 2025 – Axle end limit block and rh bracket assy – G1201-2712018159.S1A
Category: 2025 > – > M060DW3E0M012
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M16*50EpZn-8.8 | 4011000269 | 2 |
| 2 | Washer GB97.1-16EpZn-300HV | 4015000181 | 9 |
| 3 | Nut GB6185.1-M16EpZn-8 | 4013010122 | 4 |
| 4 | Lower limit block of the frame | 4110001108 | 2 |
| 5 | Brkt axle rh | 27120171402 | 1 |
| 6 | BOLT GB5786-M16*1.5*40flZnyc-12.9-480 | 4011010582 | 4 |
| 7 | Bolt GB5785-M16*1.5*140flZnyc-12.9-480 | 4011010583 | 1 |
| 8 | Nut GB6185.2-M16*1.5flZnyc-12-480 | 4013010255 | 1 |
| 9 | Bolt GB5783-M16*55EpZn-8.8 | 4011000612 | 2 |
