LGMG RTH100 2025 – Chassis mid elec module – K2000-2720021891.S1A
Category: 2025 > RTH100 > R1000Y3A0A225
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB96.1-6flZnyc-300HV-480 | 4015010296 | 2 |
| 2 | Washer GB97.1-6flZnyc-300HV-480 | 4015010284 | 2 |
| 3 | Nut GB6170-M6flZnyc-8-480 | 4013010293 | 2 |
| 4 | Low voltage cable bracket 80*35*20 | 27200155291 | 2 |
| 5 | Holder | 27200142381 | 1 |
| 6 | Bolt GB5783-M5*25flZnyc-8.8-480 | 4011011536 | 2 |
| 7 | Washer GB97.1-5flZnyc-300HV-480 | 4015010283 | 6 |
| 8 | Nut GB6170-M5flZnyc-8-480 | 4013010298 | 4 |
| 9 | Angle sensor SYSA | 4130703168 | 2 |
| 10 | Tilt angle sensor bracket 217*130*3 | 27200166321 | 1 |
| 11 | Air pressure sensor YG2221SLN | 4130000990 | 2 |
| 12 | Bolt GB5783-M5*16flZnyc-8.8-480 | 4011010958 | 2 |
| 13 | Bolt GB5783-M10*25flznyc-8.8-480 | 4011010722 | 2 |
| 14 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 2 |
| 15 | Parking pressure switch 0.55MPa | 4130000006 | 1 |
| 16 | Wheel speed sensor harness | 27200162052 | 1 |
| 17 | Electromagnetic valve air pressure switch 0.3MPa | 4130000007 | 1 |
| 18 | Brake light switchYLK17 | 4130712659 | 1 |
| 19 | Bracket 190*100*80 | 27200219031 | 1 |
| 20 | Bracket 100*90*80 | 27200219021 | 1 |
| 21 | Bolt GB5783-M10*25flZnyc-10.9-480 | 4011010845 | 4 |
| 22 | Washer GB96.1-10flZnyc-300HV-480 | 4015010278 | 4 |
| 23 | Body raised indicator xjk-1 | 4130714482 | 1 |
| 24 | Bolt GB5783-M6*30flznyc-8.8-480 | 4011010717 | 2 |
