LGMG CMT106 Mine Truck – Parking brake assy – J1100-2711010289
Category: Mine Truck > CMT106 > C1060WA00
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27160110651 | 1 |
| 2 | Nut GB6170-M12EpZn-8 | 4013000011 | 4 |
| 3 | Washer GB97.1-12EpZn-300HV | 4015000168 | 4 |
| 4 | Accumulator abutment NXJ-B1 | 4120001912 | 1 |
| 5 | Accumulator NXQ-A-2.5/31.5-L-Y | 4120001987 | 1 |
| 6 | Nipple | 23220000531 | 1 |
| 7 | WASHER JB1002-42-T2 | 4015000118 | 1 |
| 8 | Combination joint LGB143-01810 | 4041001063 | 1 |
| 9 | Accumulator clamp | 4120000736 | 1 |
| 10 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 2 |
| 11 | Hose LGB128-005300 | 4041010313 | 1 |
| 12 | Bolt GB5783-M12*50EpZn-8.8 | 4011000092 | 4 |
| 13 | Straight joint 1CO-16-04 | 4190000983 | 2 |
| 14 | Brake caliper | 4120000731 | 2 |
| 15 | Tee CC-16 | 4190001018 | 1 |
| 16 | Bolt GB16674.1-M10*110EpZn-8.8 | 4011000532 | 4 |
| 17 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 4 |
| 18 | Rubber block | 27160111031 | 1 |
| 19 | Rubber block | 27160111021 | 1 |
| 20 | Cover plate | 27160110661 | 2 |
| 21 | Washer GB97.1-10EpZn-300HV | 4015000162 | 8 |
| 22 | Hose LGB128-005144 | 4041000842 | 1 |
| 23 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 4 |
| 24 | Joint 1CO-18-06 | 4120001339 | 3 |
| 25 | Bolt GB16674.1-M10*30EpZn-8.8 | 4011000475 | 4 |
| 26 | Handle valve GL662S-102-138 | 4120001979 | 1 |
| 27 | Hose LGB165-005140 | 4041001143 | 1 |
| 28 | Hose LGB129-0040105 | 4041010314 | 1 |
| 29 | String casing | 27140105021 | 1 |
| 30 | Hose | 27100108661 | 1 |
| 31 | Hose LGB127-005070 | 4041010315 | 1 |
| 32 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 33 | Washer GB97.1-8EpZn-300HV | 4015000072 | 2 |
