LGMG Off-Highway Dump Truck 2023 – Oil Radiator assy – A0300-2703014604
Category: 2023 > Off-Highway Dump Truck > CMT106 > C1060W3E0A109
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27030122771 | 2 |
| 2 | Ubolt | 27030120641 | 6 |
| 3 | Washer GB96.1-8EpZn-300HV | 4015000256 | 16 |
| 4 | Nut GB6170-M8EpZn-8 | 4013000033 | 28 |
| 5 | Pipe | 27030122741 | 1 |
| 6 | Pipe | 27030123211 | 1 |
| 7 | Pipe | 27030142431 | 2 |
| 8 | Pipe | 27030123221 | 1 |
| 9 | Pipe | 27030123241 | 1 |
| 10 | COVER ASSEMBLY | 27030113822 | 2 |
| 11 | Pipe | 27030143781 | 2 |
| 12 | WITHIN BEAM | 27030112491 | 4 |
| 13 | RIGHT CARLING | 27030112501 | 2 |
| 14 | Oil radiator assembly | 27030146131 | 1 |
| 15 | Support4 | 27030122451 | 2 |
| 16 | Plate | 27030123201 | 2 |
| 17 | Pipe clamp LGB167-1060 | 4041000867 | 2 |
| 18 | Cushion sleeve LGB123-1060 | 4041000866 | 2 |
| 19 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 4 |
| 20 | Bolt GB5783-M12*30EpZn-8.8 | 4011000089 | 2 |
| 21 | Washer GB97.1-12EpZn-300HV | 4015000168 | 2 |
| 22 | T-bolt clamp φ68-φ76 | 4190707306 | 22 |
| 23 | Nut GB6170-M12EpZn-8 | 4013000011 | 2 |
| 24 | Bolt GB5782-M10*50EpZn-8.8 | 4011000048 | 10 |
| 25 | Washer GB97.1-10EpZn-300HV | 4015000162 | 27 |
| 26 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 19 |
| 27 | Bolt GB5782-M10*35EpZn-8.8 | 4011010164 | 4 |
| 28 | Pipe | 27030145771 | 1 |
| 29 | Pipe KA201-20-1000 | 4110705207-001 | 1 |
| 30 | Pipe component IH001506 | 4110702838-001 | 1 |
| 31 | Straight joint | 4110704929 | 1 |
| 32 | 135°Joint | 4110704928 | 3 |
| 33 | Pipe | 27030122751 | 1 |
| 34 | O-ring 37.47*3（IH004104） | 4110702846 | 4 |
| 35 | Bolt GB5782-M10*100EpZn-8.8 | 4011000817 | 4 |
| 36 | Plate | 27030123181 | 1 |
| 37 | Plate | 27030123191 | 1 |
| 38 | Pipe | 27030144141 | 3 |
| 39 | Pipe clamp R-D40-M10 | 4190707973 | 2 |
| 40 | Bolt GB5783-M10*25EpZn-10.9 | 4011000993 | 9 |
| 41 | Pipe | 27030121391 | 1 |
| 42 | Pipe | 27030122951 | 1 |
| 43 | Support1 | 27030122671 | 1 |
| 44 | Pipe | 27030123231 | 1 |
| 45 | Support2 | 27030122681 | 1 |
| 46 | Support3 | 27030122691 | 1 |
