LGMG MT85 Mine Truck – Radiator assy – A0300-2703011592
Category: Mine Truck > MT85 > M0850HE00
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB96.1-10EpZn-300HV | 4015000197 | 8 |
| 2 | Radiator shock absorber assy | 4110001445 | 2 |
| 3 | T-Clamp 78-86 | 4190002212 | 1 |
| 4 | Engine inlet hose | 27030115941 | 1 |
| 5 | Bolt GB5782-M14*85EpZn-8.8 | 4011010630 | 2 |
| 6 | Plate | 27030109731 | 2 |
| 7 | Nut GB6185.1-M14EpZn-8 | 4013010121 | 2 |
| 8 | Intercooler inlet air pipe | 27030115951 | 1 |
| 9 | No longer used | 4019010101 | 3 |
| 10 | Engine outlet water pipe | 27030115961 | 1 |
| 11 | EXPANSION TANK | 27030109101 | 1 |
| 12 | Radiator assy | 4110001737 | 1 |
| 13 | No longer used | 4019010211 | 4 |
| 14 | Intercooler outlet air pipe | 27030115971 | 1 |
| 15 | Radiator shield plate assembly | 27030109681 | 1 |
| 16 | Glass fiber Reinforced plastic wind guide cover | 4110702797 | 1 |
| 17 | Radiator bar | 4110001451 | 2 |
| 18 | Nut GB6170-M12EpZn-8 | 4013000011 | 6 |
| 19 | Support | 27030109692 | 2 |
| 20 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 4 |
| 21 | Plate | 27030109021 | 2 |
| 22 | Nut GB6171-M14*1.5EpZn-8 | 4013000119 | 8 |
| 23 | Bolt GB5783-M10*90EpZn-8.8 | 4011000956 | 4 |
