LGMG ？？2？？？？？？？？？？？o Hydrualic Excavator 2024 – Pilot line – F1102-2611020286.S1C
Category: 2024 > ？？2？？？？？？？？？？？o Hydrualic Excavator > ME106 > E10600P3A004
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Combination joint LGB143-01810 | 4041001063 | 1 |
| 2 | Hose F481CACF121206-785 | 4120711170 | 1 |
| 3 | Bolt GB16674.1-M8*16flZnyc-8.8-480 | 4011010964 | 1 |
| 4 | Washer GB97.1-8flZnyc-300HV-480 | 4015010280 | 1 |
| 5 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 1 |
| 6 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 1 |
| 7 | Nut GB6170-M10flZnyc-8-480 | 4013010289 | 1 |
| 8 | Bracket 55*50*18 | 26110203741 | 1 |
| 9 | Pipe clamp LGB169-A15*12.5 | 4041002377 | 1 |
| 10 | RECT ring LGB176-11416 | 4041003525 | 10 |
| 11 | Straight joint LGB177-21814 | 4041002962 | 1 |
| 12 | Hose F481CACE121206-1810 | 4120711791 | 1 |
| 13 | Joint | 26110201652 | 3 |
| 14 | Hose F481CACF121206-820 | 4120711169-001 | 1 |
| 15 | Nipple | 26110202961 | 3 |
| 16 | No longer used | 4041010600 | 1 |
| 17 | JOINT LGB143-11810 | 4041001464 | 1 |
| 18 | Tee LGB175-0181818 | 4041010961 | 1 |
