LGMG AT40 2025 – Bracket assy 06 – J1001-2710013313.S1A
Category: 2025 > AT40 > A0400W3M0A106
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5782-M8*70EpZn-8.8 | 4011000591 | 2 |
| 2 | Nut GB6170-M8EpZn-8 | 4013000033 | 2 |
| 3 | Washer GB97.1-8EpZn-300HV | 4015000072 | 2 |
| 4 | Plate 180*30*6 | 27100133111 | 1 |
| 5 | Clamp 13-17-32 | 27100133101 | 2 |
| 6 | Bracket 182*150*120/6 | 27100133141 | 1 |
| 7 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 2 |
| 8 | Nut GB6170-M10EpZn-8 | 4013000007 | 2 |
| 9 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
