LGMG Off-Highway Dump Truck 2024 – Lh walkway assy – L3600-2736021794.S1A
Category: 2024 > Off-Highway Dump Truck > MTE106H > C106HE0A0A504
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plate | 27360126373 | 1 |
| 2 | Guard 1831*70*3 | 27360218051 | 1 |
| 3 | Mudflap hold-down strip 715*40*4 | 27360218071 | 1 |
| 4 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 12 |
| 5 | Mudflap 1100*720*5 | 27360218061 | 1 |
| 6 | Guardrail installation | 27360218031 | 1 |
| 7 | Rearview mirror sl-723b | 4190711961 | 1 |
| 8 | Main outside rearview mirror sl-631 | 4190711593 | 1 |
| 9 | Wide-angle rearview mirror sl-632 | 4190711596 | 1 |
| 10 | Bolt GB5783-M6*35flZnyc-8.8-480 | 4011010998 | 1 |
| 11 | Bolt GB5783-M10*30flznyc-8.8-480 | 4011010707 | 22 |
| 12 | Nut GB6170-M6flZnyc-8-480 | 4013010293 | 1 |
| 13 | Bolt GB5783-M14*50flZnyc-12.9-480 | 4011010549 | 2 |
| 14 | Washer GB96.1-14flZnyc-300HV-480 | 4015010371 | 8 |
| 15 | Washer GB97.1-14flZnyc-300HV-480 | 4015010341 | 2 |
| 16 | Nut GB6185.1-M14flZnyc-12-480 | 4013010253 | 5 |
| 17 | Bolt GB5782-M14*120flZnyc-12.9-480 | 4011011729 | 3 |
| 18 | Washer GB96.1-10flZnyc-300HV-480 | 4015010278 | 52 |
| 19 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 44 |
| 20 | Left wheel cover | 27360108021 | 1 |
| 21 | Bolt GB5783-M10*25flznyc-8.8-480 | 4011010722 | 4 |
| 22 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 36 |
| 23 | Rearward illumination lamp bracket | 27360164651 | 1 |
| 24 | Bolt GB5783-M10*70flZnyc-8.8-480 | 4011011342 | 6 |
| 25 | Lh walkway wldmt | 27360217951 | 1 |
