LGMG CMT96A 2025 – Hydraulic oil tank installation – M1601-2716013637.S1A
Category: 2025 > CMT96A > C096AY3E0A006
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Hydraulic oil tank assembly | 27160116563 | 1 |
| 2 | Hydraulic oil tank bracket assembly | 27160108901 | 2 |
| 3 | Tube | 27160109731 | 2 |
| 4 | Hydraulic tank plate | 27160115241 | 3 |
| 5 | Bolt GB5782-M16*140EpZn-10.9 | 4011010495 | 2 |
| 6 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 4 |
| 7 | Bolt GB5782-M16*130EpZn-10.9 | 4011010363 | 2 |
| 8 | Washer GB97.1-12EpZn-300HV | 4015000168 | 2 |
| 9 | Nut GB6170-M12EpZn-8 | 4013000011 | 4 |
