LGMG Mine Truck 2026 – Elec module for low power devices – K3401-2734013261.S1A
Category: 2026 > Mine Truck > MTH116 > C1160Y3A0A006
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | L-bracket 180*114*50 | 27340127841 | 1 |
| 2 | Pipe clamp 2*18.5-140*30*20 | 27340132621 | 2 |
| 3 | Bolt gb16674.1-m10*65flznyc-8.8-480 | 4011011903 | 6 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 2 |
| 5 | Nut gb6187.1-m10flznyc-8-480 | 4013010628 | 52 |
| 6 | Bolt GB16674.1-M10*30flZnyc-8.8-480 | 4011010712 | 11 |
| 7 | L-bracket 122*65*4 | 27340130941 | 2 |
| 8 | Bolt gb16674.1-m10*80flznyc-8.8-480 | 4011011904 | 15 |
| 9 | L-bracket 50*50*4 | 27340124371 | 1 |
| 10 | Cable tie HS-J117 | 4130704969 | 18 |
| 11 | No.1 dc wire (+) 6220 | 2734012768-004 | 1 |
| 12 | Bolt GB16674.1-M10*20flZnyc-8.8-480 | 4011010993 | 4 |
| 13 | L-bracket 185*55*4 | 27340130921 | 1 |
| 14 | Pipe clamp 2*18.5-2*24.5-179*30*20 | 27340132631 | 2 |
| 15 | Z-bracket 211*50*4 | 27340127881 | 1 |
| 16 | Bolt GB16674.1-M10*25flZnyc-8.8-480 | 4011011015 | 5 |
| 17 | Bracket 2 | 27340104491 | 3 |
| 18 | L-bracket 175*35*5 | 27340132651 | 3 |
| 19 | Bolt GB16674.1-M10*35flZnyc-8.8-480 | 4011011104 | 2 |
| 20 | Pipe clamp 2*18.5-2*24.5-142*30*20 | 27340132641 | 6 |
| 21 | Bracket 115*70*60 | 27340125401 | 3 |
| 22 | Oil pump high voltage wire 3015 | 2734012763-004 | 1 |
| 23 | L-bracket 106*60*40 | 27340125411 | 2 |
| 24 | L-bracket 130*106*60 | 27340125391 | 1 |
| 25 | Washer GB862.2-10-65Mn | 4015010586 | 2 |
| 26 | Bracket 45 | 27030139931 | 1 |
| 27 | Bolt GB16674.1-M10*40flZnyc-8.8-480 | 4011011086 | 11 |
| 28 | Pipe clamp 4*18.5-1*24.5-160*30*20 | 27340127911 | 2 |
| 29 | Bolt GB16674.1-M10*60flZnyc-8.8-480 | 4011011093 | 4 |
| 30 | Bolt GB5783-M10*20EpZn-8.8 | 4011000081 | 2 |
| 31 | Air conditioner high voltage wire 5810 | 2734012766-004 | 1 |
| 32 | Bolt GB16674.1-M8*30EpZn-8.8 | 4011000481 | 1 |
| 33 | Double sack wedge lock washer HF10 | 4190708409 | 2 |
| 34 | No.2 dc wire (+) 3760 | 2734012770-004 | 1 |
| 35 | Air pump high voltage wire 4295 | 2734012762-004 | 1 |
| 36 | No.1 dc wire (-) 1520 | 2734012769-004 | 1 |
| 37 | No.2 dc wire (-) 1135 | 2734012771-004 | 1 |
