LGMG Mine Truck Mine Truck – Transmission support assembly – C0501-2705010438
Category: Mine Truck > Mine Truck > MT400WA00
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M16*70EpZn-10.9 | 4011010204 | 2 |
| 2 | Damper plate | 27050103881 | 4 |
| 3 | Auxiliary support shock absorber 44003-13 | 4190001505 | 2 |
| 4 | Plate | 27050104411 | 1 |
| 5 | Bolt GB5783-M16*45EpZn-8.8 | 4011000205 | 2 |
| 6 | Washer 16 | 27150105311 | 4 |
| 7 | Intermediate shoe | 27050104121 | 1 |
| 8 | Right anchorage | 27050104602 | 1 |
| 9 | Bolt GB5782-M16*130EpZn-10.9 | 4011010363 | 2 |
| 10 | Nut GB6170-M16EpZn-10 | 4013000205 | 8 |
| 11 | No longer used | 4015000305 | 2 |
| 12 | TUNING WASHER | 27050104201 | 2 |
| 13 | Adjusting gasket | 27050103661 | 2 |
| 14 | Adjusting gasket | 27050103671 | 2 |
| 15 | Left anchorage | 27050104562 | 1 |
| 16 | Nut GB6185.1-M18EpZn-8 | 4013010123 | 8 |
| 17 | Washer GB97.1-18EpZn-300HV | 4015000182 | 8 |
| 18 | Bolt GB5782-M18*60EpZn-8.8 | 4011000367 | 8 |
