LGMG Mine Truck 2026 – Body assy – P1705-2717052732.S1A
Category: 2026 > Mine Truck > MT50 > M0500Y3E0M402
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Connecting yoke | 27170297203 | 2 |
| 2 | Plate | 27170366964 | 4 |
| 3 | Pin GB91-5*45EpZn-Q235A | 4016010004 | 4 |
| 4 | Nut GB6178-M16EpZn-8 | 4013000057 | 4 |
| 5 | Φ16 CHAIN | 27170123461 | 2 |
| 6 | Plate | 27170366972 | 2 |
| 7 | Nut GB6178-M24EpZn-10 | 4013010219 | 2 |
| 8 | Pin GB91-6.3*50EpZn-Q235A | 4016000040 | 2 |
| 9 | Plate | 27170346761 | 2 |
| 10 | Bolt GB5786-M12*1.5*35EpZn-8.8 | 4011010010 | 8 |
| 11 | Mud skin | 27170171821 | 1 |
| 12 | Washer GB97.1-12EpZn-300HV | 4015000168 | 12 |
| 13 | Upper limit plate 260*85*8 | 27170382611 | 2 |
| 14 | Side limit adjusting gasket | 27170171791 | 4 |
| 15 | Side limit adjusting gasket | 27170171801 | 2 |
| 16 | Side limit adjusting gasket | 27170171811 | 2 |
| 17 | Body lh outer hinge lug wldmt | 27170396331 | 1 |
| 18 | Grease nipple JB7940.1-M10*1 | 4030000065 | 2 |
| 19 | Butter nozzle cap JXHF-00006 | 4120000015 | 2 |
| 20 | Bolt gb5786-m24*2*60epzn-10.9 | 4011011739 | 12 |
| 21 | Washer din6796-24-65mn | 4015010594 | 12 |
| 22 | Bolt GB5783-M8*35EpZn-8.8 | 4011000195 | 10 |
| 23 | Plate | 27170389181 | 2 |
| 24 | Plate | 27170389191 | 2 |
| 25 | Plate | 27170389201 | 2 |
| 26 | Body hinge lug shim 100*60*2 | 27170396542 | 8 |
| 27 | Body hinge lug shim 100*60*1 | 27170396552 | 4 |
| 28 | Body hinge lug shim 100*60*0.5 | 27170396562 | 4 |
| 29 | Body lh inner hinge lug wldmt | 27170396381 | 1 |
| 30 | Body hinge baseplate shim 275*123*2 | 27170396441 | 2 |
| 31 | Body hinge baseplate shim 275*123*1 | 27170396451 | 2 |
| 32 | Body hinge baseplate shim 275*123*3 | 27170396461 | 1 |
| 33 | Washer GB96.1-8EpZn-300HV | 4015000256 | 20 |
| 34 | Pin wldmt | 27170382632 | 2 |
| 35 | Cover plate 120*35*10 | 27170382621 | 2 |
| 36 | Bolt GB5782-M12*35EpZn-8.8 | 4011000061 | 4 |
| 37 | Body rh inner hinge lug wldmt | 27170396431 | 1 |
| 38 | Body rh outer hinge lug wldmt | 27170396371 | 1 |
| 39 | Body shell | 27170527331 | 1 |
| 40 | Nut GB6185.1-M8EpZn-8 | 4013010118 | 10 |
| 41 | Plate | 27170171831 | 2 |
| 42 | Plate | 27170171841 | 2 |
| 43 | Mud skin | 27170171851 | 1 |
| 44 | Nut GB6172.1-M30EpZn-8 | 4013000175 | 4 |
| 45 | Nut GB6170-M30EpZn-8 | 4013000173 | 4 |
