LGMG Off-Highway Dump Truck 2024 – Service brake assy – J1001-2710012819.S1A
Category: 2024 > Off-Highway Dump Truck > CMT66A > C066AW3E0A002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB97.1-12EpZn-300HV | 4015000168 | 2 |
| 2 | Nut GB6170-M12EpZn-8 | 4013000011 | 2 |
| 3 | Bolt GB5783-M16*50EpZn-8.8 | 4011000269 | 2 |
| 4 | Nut GB6170-M16EpZn-8 | 4013000016 | 2 |
| 5 | Installation assembly | 27100120811 | 1 |
| 6 | Module installation assembly | 27100120881 | 1 |
| 7 | Asm | 27100121251 | 1 |
| 8 | Air hose gpu-13-i-770-sg | 27100103751 | 4 |
| 9 | Nipple | 27100118011 | 10 |
| 10 | Bracket 100*25*33*3 | 27100131321 | 2 |
| 11 | Current box bracket assembly | 27100120841 | 1 |
| 12 | Plate | 27100120611 | 1 |
| 13 | Air hose GPU-13-I-880-SG | 2710010744-025 | 4 |
| 14 | Combination joint LGB143-01205 | 4041010126 | 1 |
| 15 | Accessories installation | 27100128181 | 1 |
| 16 | Brake air lines assy | 2710012075-001 | 1 |
| 17 | Plate | 27100118691 | 1 |
| 18 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 1 |
| 19 | Washer GB97.1-10EpZn-300HV | 4015000162 | 1 |
| 20 | Nut GB6170-M10EpZn-8 | 4013000007 | 1 |
| 21 | Bolt GB5783-M16*50EpZn-10.9 | 4011000742 | 4 |
| 22 | Washer GB97.1-16EpZn-300HV | 4015000181 | 8 |
| 23 | Nut GB6185.1-M16EpZn-10 | 4013010136 | 6 |
| 24 | Bolt GB5782-M16*200EpZn-10.9 | 4011010020 | 2 |
| 25 | Sensor | 27100118001 | 1 |
| 26 | Break valve | 27100120781 | 1 |
| 27 | Dryer asm | 27100120761 | 1 |
| 28 | Bolt GB5783-M12*50EpZn-8.8 | 4011000092 | 2 |
