LGMG CMT106H 2025 – Charging socket assy – K6200-2762000758.S1A
Category: 2025 > CMT106H > C106HE0A0A701
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Dc charging socket 1 | 4130713329 | 1 |
| 2 | Pipe clamp half 165*35*20 | 27620004941 | 4 |
| 3 | Tube bank plate 165*25*35 | 27620003881 | 8 |
| 4 | Cable tie HS-J117 | 4130704969 | 6 |
| 5 | Bracket 165*60*75 | 27620005002 | 4 |
| 6 | Bolt GB5783-M10*30flznyc-8.8-480 | 4011010707 | 20 |
| 7 | Nut GB6185.1-M10flZnyc-8-480 | 4013010292 | 92 |
| 8 | Bolt GB5782-M10*110flZnyc-8.8-480 | 4011011204 | 4 |
| 9 | Sleeve 276*106*12 | 27620003861 | 6 |
| 10 | Protection | 27620003291 | 2 |
| 11 | Bolt GB5783-M6*25flZnyc-8.8-480 | 4011010731 | 12 |
| 12 | Protection116*96*15 | 27620003931 | 4 |
| 13 | Tube bank plate 100*35*17 | 27620003921 | 76 |
| 14 | Bracket 100*60*35 | 27620005951 | 1 |
| 15 | Bolt GB5782-M10*90EpZn-8.8 | 4011000053 | 37 |
| 16 | L-bracket 125*40*60 | 27620003871 | 4 |
| 17 | Bolt GB5782-M10*100flZnyc-8.8-480 | 4011011157 | 1 |
| 18 | Z-bracket 180*20*25 | 27620004121 | 2 |
| 19 | L-bracket 165*70*35 | 27620007481 | 1 |
| 20 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 10 |
| 21 | Bracket 210*125*35 | 27620007501 | 2 |
| 22 | Washer GB97.1-6flZnyc-300HV-480 | 4015010284 | 32 |
| 23 | Z-bracket 160*80*44 | 27620004951 | 3 |
| 24 | L-bracket 165*110*35 | 27620007491 | 1 |
| 25 | L-bracket 130*85*27 | 27620007511 | 1 |
| 26 | Bracket 165*30*6 | 27620004991 | 1 |
| 27 | Bracket 100*60*35 | 27620005941 | 1 |
| 28 | Grommet 96*76*14 | 27620004601 | 2 |
| 29 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 2 |
| 30 | Double sack wedge lock washer HF10 | 4190708409 | 2 |
| 31 | Washer GB97.1-10EpZn-300HV | 4015000162 | 4 |
| 32 | Washer GB862.2-10-65Mn | 4015010586 | 2 |
| 33 | Nut GB6185.1-M6flZnyc-8-480 | 4013010414 | 16 |
| 34 | Nut GB6185.1-M10EpZn-8 | 4013010119 | 2 |
| 35 | Bolt GB5782-M10*75flZnyc-8.8-480 | 4011010724 | 2 |
| 36 | Bolt GB5782-M10*80flZnyc-8.8-480 | 4011010779 | 2 |
| 37 | Bolt GB5783-M10*25flznyc-8.8-480 | 4011010722 | 30 |
| 38 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 196 |
| 39 | Dc charging socket 4 | 4130713332 | 1 |
| 40 | Dc charging socket 3 | 4130713331 | 1 |
| 41 | Harness protective plate 858*389*2 | 27620003851 | 2 |
| 42 | Dc charging socket 2 | 4130713330 | 1 |
