LGMG CMT66 2025 – Bracket assy 01 – H1501-2715014123.S1A
Category: 2025 > CMT66 > C0660Y3E0A001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Pipe rubber clamp assy | 27150120831 | 1 |
| 2 | Bracket 168*110*30 | 27150141341 | 1 |
| 3 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 1 |
| 4 | Washer GB97.1-10EpZn-300HV | 4015000162 | 1 |
| 5 | Nut GB6170-M10EpZn-8 | 4013000007 | 1 |
