LGMG ？？？a？2？？？？？？？°a？2？¨？？？| 2025 – Shift control installation – C0501-2705012456.S1A-G1
Category: 2025 > ？？？a？2？？？？？？？°a？2？¨？？？| > MS25 > MS250Y3E0M002
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Washer GB848-8EpZn-300HV | 4015010215 | 7 |
| 2 | Manipulator connecting block | 27050101511 | 1 |
| 3 | Pad of paper | 27050101521 | 1 |
| 4 | Controller | 27050101531 | 1 |
| 5 | Bolt GB5782-M8*45EpZn-8.8 | 4011000298 | 2 |
| 6 | Washer GB97.1-8EpZn-300HV | 4015000072 | 5 |
| 7 | Bolt GB5783-M8*30EpZn-8.8 | 4011000107 | 2 |
| 8 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 1 |
| 9 | Flexshaft clamp | 27050101691 | 1 |
| 10 | Grommet | 27050109751 | 1 |
| 11 | The selector flexible shaft assembly | 27050101551 | 1 |
| 12 | Bolt GB5783-M6*25EpZn-8.8 | 4011000276 | 1 |
| 13 | Nut GB6170-M6EpZn-8 | 4013000028 | 5 |
| 14 | Washer GB96.1-6EpZn-300HV | 4015000198 | 5 |
| 15 | Bracket 150*30*20 | 27200166451 | 1 |
| 16 | Bolt GB5783-M10*45EpZn-8.8 | 4011000514 | 6 |
| 17 | Washer GB97.1-10EpZn-300HV | 4015000162 | 6 |
| 18 | Bolt GB5782-M6*50EpZn-8.8 | 4011000523 | 2 |
| 19 | Washer GB97.1-6EpZn-300HV | 4015000207 | 2 |
| 20 | Clamp for 2 pipes TTPG16-214 | 4120712759 | 2 |
| 21 | Support ⅰ | 27050106571 | 1 |
| 22 | Shifting flexible shaft assy | 4110001724 | 1 |
| 23 | Nut GB6170-M10EpZn-8 | 4013000007 | 7 |
| 24 | Retaining plate 230*30*4 | 27150134271 | 2 |
| 25 | Bolt GB5783-M6*25flZnyc-8.8-480 | 4011010731 | 2 |
| 26 | Bracket | 27050109821 | 1 |
| 27 | Pipe clamp LGB167-0116 | 4041001132 | 2 |
| 28 | Cushion sleeve LGB123-0116 | 4041001252 | 2 |
| 29 | Selecting flexible shaft bracket | 4110000515 | 1 |
| 30 | Shifting flexible shaft bracket | 4110000546 | 1 |
| 31 | Bolt GB5782-M10*30EpZn-8.8 | 4011010174 | 2 |
| 32 | Washer GB96.1-10EpZn-300HV | 4015000197 | 2 |
| 33 | Shift handle crank assembly | 27050105331 | 1 |
| 34 | Selecting rocker arm | 4110000545 | 1 |
| 35 | Bolt GB5783-M8*40EpZn-8.8 | 4011000299 | 1 |
| 36 | Nut GB889.1-M8EpZn-8 | 4013000210 | 1 |
| 37 | Dust cover | 4110000209 | 1 |
| 38 | Nut GB6170-M12EpZn-8 | 4013000011 | 2 |
| 39 | Washer GB848-12EpZn-300HV | 4015000004 | 1 |
| 40 | Shift lever | 27050124611 | 1 |
| 41 | Washer GB93-12-65Mn | 4015000026 | 1 |
| 42 | Screw GB70.1-M8*25-8.8 | 4014000171 | 6 |
