LGMG Off-Highway Dump Truck 2023 – Frame harness mounting assy – K2001-2720016181
Category: 2023 > Off-Highway Dump Truck > EL100 > R1260Y3A0A602
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M6*16EpZn-8.8 | 4011000289 | 1 |
| 2 | Bracket | 27340110611 | 2 |
| 3 | Cable tie 14400342 | 4130703098 | 3 |
| 4 | Holder | 27200153071 | 3 |
| 5 | Bolt GB5783-M10*65flZnyc-10.9-480 | 4011011565 | 2 |
| 6 | Grommet 159*144*6 | 27200154601 | 1 |
| 7 | Itt plate | 27200125031 | 1 |
| 8 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 1 |
| 9 | Washer GB97.1-8EpZn-300HV | 4015000072 | 6 |
| 10 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 6 |
| 11 | Frame harness | 27200161381 | 1 |
| 12 | Nut GB6170-M8EpZn-8 | 4013000033 | 6 |
| 13 | Jacket | 27200154051 | 3 |
| 14 | Cable tie HS-J117 | 4130704969 | 5 |
| 15 | Nut GB6170-M10EpZn-8 | 4013000007 | 16 |
| 16 | Bolt GB5783-M10*35EpZn-8.8 | 4011000085 | 13 |
| 17 | Washer GB97.1-10EpZn-300HV | 4015000162 | 89 |
| 18 | Bolt GB5783-M10*20EpZn-8.8 | 4011000081 | 75 |
| 19 | Holder | 27200141551 | 37 |
| 20 | Double sack wedge lock washer HF10 | 4190708409 | 2 |
| 21 | Holder | 27200142471 | 30 |
| 22 | Washer GB862.2-10-65Mn | 4015010586 | 2 |
| 23 | Holder | 27200142321 | 28 |
| 24 | Washer GB97.1-6EpZn-300HV | 4015000207 | 1 |
