LGMG Off-Highway Dump Truck 2023 – Lifting valve attachment – M1601-2716013303.S1A
Category: 2023 > Off-Highway Dump Truck > CMTE106H > C106HE0A0A403
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Plug LGB135-03341 | 4041000192 | 1 |
| 2 | Copper washer 10 | 27100101091 | 2 |
| 3 | Lifting valve | 4120002439 | 1 |
| 4 | Connector | 27160122773 | 1 |
| 5 | Straight joint LGB120-03633 | 4041000577 | 1 |
| 6 | O-ring LGB168-12931 | 4041000765 | 4 |
| 7 | Check valve SY-RZ-L28-JM33*2-DN25-0.5 | 4120708099 | 1 |
| 8 | Joint-m33 | 27160133041 | 1 |
| 9 | Combination joint LGB143-01205 | 4041010126 | 2 |
| 10 | Vertical nipple | 27130111131 | 2 |
| 11 | Tee joint CC-12 | 4190001064 | 1 |
