LGMG Off-Highway Dump Truck 2024 – Engine electrical system – K3401-2734011449.S1A
Category: 2024 > Off-Highway Dump Truck > CMT106F > C1060W4E0A001
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Cable tie HS-J117 | 4130704969 | 10 |
| 2 | Nut GB6170-M8EpZn-8 | 4013000033 | 15 |
| 3 | Transmission bracket 652.8*54*80 | 27340111951 | 1 |
| 4 | Itt connector bracket 70*70*30 | 27200148871 | 1 |
| 5 | Bolt GB5783-M10*25EpZn-8.8 | 4011000082 | 1 |
| 6 | Washer GB97.1-10EpZn-300HV | 4015000162 | 15 |
| 7 | Nut GB6170-M10EpZn-8 | 4013000007 | 14 |
| 8 | Bolt GB5783-M10*30EpZn-8.8 | 4011000084 | 6 |
| 9 | Bolt GB5783-M12*40EpZn-8.8 | 4011000091 | 2 |
| 10 | Washer GB97.1-12EpZn-300HV | 4015000168 | 2 |
| 11 | Engine harness | 27340114501 | 1 |
| 12 | Nut GB6170-M12EpZn-8 | 4013000011 | 2 |
| 13 | String casing | 27140105021 | 1 |
| 14 | Bolt GB5783-M8*20EpZn-8.8 | 4011000105 | 1 |
| 15 | Washer GB96.1-8EpZn-300HV | 4015000256 | 1 |
| 16 | Bolt GB5783-M10*40EpZn-8.8 | 4011000184 | 8 |
| 17 | Nut GB6170-M6EpZn-8 | 4013000028 | 1 |
| 18 | Nylon cap nut M8 | 4130705735 | 1 |
| 19 | Transmission harness | 27340114781 | 1 |
| 20 | Holder | 27200142321 | 4 |
| 21 | Cable tie 14400342 | 4130703098 | 8 |
| 22 | Bolt GB5783-M6*20EpZn-8.8 | 4011000101 | 3 |
| 23 | Washer GB96.1-6EpZn-300HV | 4015000198 | 4 |
| 24 | Bolt GB5783-M8*25EpZn-8.8 | 4011000106 | 15 |
| 25 | Washer GB97.1-8EpZn-300HV | 4015000072 | 16 |
| 26 | Holder | 27200147051 | 13 |
