LGMG – 2025 – Steering accessory assy – H1501-2715013336.S1A
Category: 2025 > – > M060DW3E0M105
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Hose LGB129-006162 | 4041010338-013 | 1 |
| 2 | Combination joint LGB143-12213 | 4041001218 | 2 |
| 3 | Combination joint LGB143-12616 | 4041001417 | 1 |
| 4 | Bulkhead joint M26 | 27150109061 | 1 |
| 5 | Hose F481CACF080804-440 | 4120712195-002 | 1 |
| 6 | Tee CC-26 | 4190002536 | 1 |
| 7 | Nut | 27150103221 | 1 |
| 8 | Reducing joint RED18/08LOMDCF | 4120001300 | 1 |
| 9 | Combination joint LGB143-02616 | 4041001006 | 2 |
| 10 | Pipe assy | 27150132831 | 1 |
| 11 | Oil suck hose82*7*1640 | 27150130361 | 1 |
| 12 | Hose F451TCCACF151508-540-SG | 4120712633-001 | 1 |
| 13 | Hose F451TCCACF151508-810-SG | 4120712634-001 | 1 |
| 14 | Pipe clamps assy | 27150133141 | 1 |
| 15 | Pipe clamps assy | 27150132801 | 1 |
| 16 | Bracket assembly | 27150129831 | 1 |
| 17 | Pipe rubber clamp assy | 27150120831 | 1 |
| 18 | Bracket assy | 27150133331 | 1 |
| 19 | Clamp TTPG3-323 | 4120710492 | 1 |
| 20 | Cable tie 14400342 | 4130703098 | 3 |
| 21 | Bolt GB5783-M8*35EpZn-8.8 | 4011000195 | 3 |
| 22 | Hose F681CACA181810-2900 | 4120712073-002 | 1 |
| 23 | Hose clamp JB8870-D90 | 4017000013 | 4 |
| 24 | O-ring LGB168-12331 | 4041000779 | 1 |
| 25 | Straight joint LGB120-02628 | 4041000796 | 1 |
| 26 | HOSE -1560 | 2715011224-002 | 1 |
| 27 | Hose LGB127-006075 | 4041000699-008 | 1 |
| 28 | Hose LGB127-006075 | 4041000699-007 | 1 |
| 29 | Hose F481CACF080804-2350 | 4120707222-002 | 1 |
| 30 | Hose F681TCCACE181810-1810 | 4120712748 | 1 |
| 31 | Hose F451TCCACE151508-1770 | 4120711917-004 | 1 |
| 32 | Hose LGB129-006187 | 4041010379-010 | 1 |
