LGMG AT40 2025 – Gear pump installation – J1501-2715015195.S1A
Category: 2025 > AT40 > A0400W3M0A105
Parts List:
| No. | Part Name | Part Number | Qty |
|---|---|---|---|
| 1 | Bolt GB5783-M10*35flZnyc-8.8-480 | 4011010727 | 1 |
| 2 | Washer GB97.1-10flZnyc-300HV-480 | 4015010339 | 13 |
| 3 | Nut GB6170-M10flZnyc-8-480 | 4013010289 | 1 |
| 4 | Bolt GB5782-M10*75flZnyc-8.8-480 | 4011010724 | 4 |
| 5 | Block 84.5*70*58.4 | 27150145981 | 1 |
| 6 | Pipe wldmt 07 | 27150142552 | 1 |
| 7 | Screw GB70.1-M10*20flZnyc-10.9-480 | 4014010385 | 4 |
| 8 | O-RING GB3452.1-43.7*3.55G | 4030000235 | 2 |
| 9 | Assy | 27150142671 | 4 |
| 10 | Pipe wldmt 02 | 27150144451 | 1 |
| 11 | Bolt GB5782-M12*75flZnyc-10.9-480 | 4011011174 | 4 |
| 12 | Plug vsti42*2edcf | 4120717795 | 1 |
| 13 | O ring gbt3452.3-28*3.55 | 4120714478 | 1 |
| 14 | Nut GB6170-M12flZnyc-10-480 | 4013010343 | 2 |
| 15 | Bolt GB5782-M10*70flZnyc-8.8-480 | 4011010825 | 4 |
| 16 | Washer GB97.1-12flZnyc-300HV-480 | 4015010340 | 4 |
| 17 | Block | 27150142452 | 1 |
| 18 | Screw GB70.1-M12*35flZnyc-10.9-480 | 4014010282 | 2 |
| 19 | Washer gb848-12flznyc-300hv-480 | 4015010592 | 4 |
| 20 | Gear pump cbqtbs-c50c25-bf1h | 4120713999 | 1 |
| 21 | O ring gbt3452.1-34.5*3.55 | 4120714448 | 2 |
| 22 | Block 105*70*58.4 | 27150145971 | 1 |
| 23 | Plate 190.5*100*5 | 27150142992 | 1 |
